Automatically fill nearly every type of cartridge and POD as well as capsules, syringes and jars. Refill the glass 140ml heated oil reservoir during operation. Adjust the dispense volume precisely up to 1.1 ml. Quickly configure various tray arrays for new vape devices introduced into the market. Custom designed trays available for non-standard devices.
Dispense High and Low Viscosity Oils
Patented heated oil dispense system regulates oil viscosity. Fill high viscosity oils with extreme accuracy, precision and repeatability. Fine tune dispense speed and force for lower viscosity oils.
Rapid Oil Formula Changes and System Cleaning
Replace the food safe, laboratory grade, dispense system components in less than one minute to switch oil formulas. Rapidly clean the dispense components with less than one gram loss. Two full dispense component sets are included.
Touch Screen Controls
Control the filling operation using the simple and intuitive seven inch color touch screen. Adjust temperature and fill speed on the fly. Monitor operating parameters including cartridge tray fill status, real time diagnostics and alarms with complete alarm history.
Designed, manufactured, distributed and patented in the United States of America. Industrial control system with compliant materials and dispense components. Stainless steel check valves custom designed and manufactured specifically for oil filling applications. Exceptional customer support available for the lifetime of the machine.
Optional Data Acquisition System
The optional ACF-DA System data historian and reporting solution permanently stores a record for all system process variables for every cartridge or POD filled. The ACF-DA connects to multiple ACF1 machines.
Patented and Certified
Patented (United States Patent No. 10,440,989) and cETLus Certified for the USA and Canada (UL 61010-1, UL 61010-2, UL508, CSA C22.2, IEC 61010-1). Adheres to the rigorous Good Manufacturing Practice guidelines required for legal compliance.
Lightweight and portable benchtop design for quick and easy setup, operation, and cleaning. Requires 120V AC power and 40psi compressed air.
